Omron S82J - Page 11

S82J
S82J
11
INPUT
AC(L)
AC(N)
Fuse
(5 A)
Noise filter
Control circuit
Overload
detection
circuit
Photocoupler
Detector
+V
–V
DC Output
S82J-10024j (100 W , 24-V Output)
Rectifier Inrush current
protection
circuit
Smoothing
circuit
Rectifier and
smoothing
circuit
Photocoupler
Overload
detection
circuit
+V
–V
DC OutputInput
AC (L)
AC (N)
Fuse (8 A)
Noise filter
Inrush current
protection circuit
Rectifier
Control circuit
Overcurrent
detector
Rectifier and
smoothing
circuit
Detector
Photocoupler
S82J-15024j (150 W)
100 or 200 V
(selected au-
tomatically)
S82J-30024j (300 W)
Parallel operation selector
100/200 V (selectable)
Note: Short-circuit
the input voltage terminals if
the input is 100 to 120 V AC. Keep the ter -
minals
open if the input is 200 to 230 V AC.
Fuse
(10 A)
Noise filter
Inrush current
protection circuit
Rectifier
and
smoothing
circuit
Detector
Photocoupler
Overvoltage
detector
Photocoupler
Control
circuit
Overcurrent
detector
Rectifier and
smoothing circuit
