Omron S82J - Installation

S82J
S82J
19
Installation
10-/25-/50-/100-/150-W Models
Note: 10-/25-/50-/100 (24 V)-W models are available only as Front T erminal Models.
5
6
1
3
2
+V
–V
AC
(L)
AC (N)
5
6
1
3
2
+V
–V
AC (L)
AC (N)
5
6
1
3
2
+V
–V
AC (L)
AC (N)
NC
9
Front T erminals Model T op T erminals Model Connector Model
GR
GR
GR
Connectors
Connector
Connector on the PCB side Housing Terminal
Input W afer (Made by Molex) 5277-04A-RE Housing (Made by Molex) 5196-04-RE
or 5196-04
T erminal (Made by Molex) 5194T or
5194TL
Output T ab header (Made by Nippon AMP)
1-178140-5
Rise housing (Made by Nippon AMP)
1-178129-6
Rise contact (Made by Nippon AMP)
1-175196-5 or 1-175218-5
Note: The permissible current of the output connector is 8 A per pin.
