Specifications Table – continued from previous page
Item
Non–PFC models PFC model
Single output Dual
outputs
Single output
3 W 7.5 W 7.5 W 15 W 30 W 50 W 90 W 100 W 240 W 240 W
Other Ambient
temperature
Operating: See the derating curve in the Engineering Data section
(no condensation or icing)
Storage: –25°C to 65°C (no condensation or icing)
Other
Ambient humidity Operating: 25% to 85%
Storage: 25% to 90%
Dielectric strength 3,000 VAC at 50/60 Hz for 1 min (between all inputs and outputs)
2,000 VAC at 50/60 Hz for 1 min (between all inputs and GR terminal)
1,000 VAC at 50/60 Hz for 1 min (between all outputs and GR terminal)
Alarm current: 10 mA (3- to 7.5-W models) 20 mA (15- to 100-W models) 25 mA (240-W models)
Insulation
resistance
100 MΩ min. at 500 VDC (between all outputs and all inputs/GR terminal)
Vibration
resistance
Malfunction: 10 to 55 Hz, 0.375-mm single amplitude for 2 hrs each in X, Y,
and Z directions
Malfunction: 10 to
55 Hz, 0.15-mm single
amplitude for 2 hrs
each in X, Y, and
Z directions
Shock resistance Malfunction: 300 m/s
2
, 3 times each in ±X, ±Y, and ±Z directions
Screw tightening
torque
0.74 N  m max. (see note 2)
Output indicator Yes (green)
Electromagnetic
interference
(see note 1)
Conforms to FCC class B Conforms to FCC class A
EMC
(see note 3, 4)
3 to 100-W Models
(EMI): EN50081-1
Emission Enclosure: EN55022 class B (equivalent to EN55011 class B)
Emission AC Mains: EN55022 class B (equivalent to EN55011 class B)
Emission Output Ports: EN55022 class A (with a recommended optional filter) (see note 3)
240-W Models
(EMI): EN50081-2
Emission Enclosure: EN55011 class A (see note 4)
Emission AC Mains: EN55011 class A (see note 4)
Harmonic Current: EN61000-3-2 (only for S82K-P24024)
Common to All Models
(EMS): EN50082-2
Immunity ESD: EN61000-4-2: 4-kV contact discharge (level 2)
8-kV air discharge (level 3)
Immunity Burst: EN61000-4-4: 2-kV power-line (level 3)
2-kV output line (level 4)
Immunity Surge: EN61000-4-5: between 2-kV lines (except for 240-W models)
between 4-kV line and FG (except for 240-W models)
Approved
standards
Class 2 (UL 1310)/Class 2 (CSA C22.2 No. 950) (see notes 5 and 6)
UL 508 (Listing)/1950
CSA C22.2 No.14/No.950, EN50178 (VDE0160), EN60950
Conforms to VDE0106/P100
UL 508 (Listing)/1012
CSA C22.2 No.14,
CSA E.B. 1402C,
EN50178 (VDE0160),
EN60950
Conforms to
VDE106/P100
Weight 150 g max. 260 g
max.
380 g
max.
400 g
max.
600 g max. 1,800 g
max.
2,200 g max.
Note: 1. Defined with a 100% load and the rated input voltage (100 or 200 VAC).
2. Do not press down on the terminal block with a force exceeding 75 N while tightening the terminals.
3. To ensure the emission ratings, a noise filter should be used on the output lines at the closest point.
(3- to 50-W models: S82Y-JF3-N, 90- and 100-W models: S82Y-JF6-N)
4. To ensure the Emission Enclosure rating, a ferrite ring core should be used on all cables (for S82K-P24024).
5. Models other than dual output models satisfy the Class-2 requirements.
6. To meet Class-2 requirements with the 100-W model, either a fuse or circuit breaker that is UL listed or CSA certified, and rated
at 4.2 A max. should be wired in series with the load to be connected to the power supply. Only then can the power supply out-
put be considered as meeting Class 2.
