Omron S8VK-S Series User Manual

S8VK-S
16
Mounting Brackets
Note: Be sure to use the accessory screws.
Mounting screw tightening torque (recommended): 4.43 to 5.31 lb-in (0.5 to 0.6 N·m)
Name Model
Front-mounting bracket (for 30 W and 60 W models) S82Y-VS10F
Side-mounting bracket (for 30 W and 60 W models) S82Y-VS10S
Front-mounting bracket (for 240 W and 480 W models) S82Y-VK10F
Type Model Dimensions Appearance
Front-mounting
bracket
(For 30 W and
60 W models)
S82Y-VS10F
Side-mounting
bracket
(For 30 W and
60 W models)
S82Y-VS10S
Front-mounting
bracket
(For 240 W and
480 W models)
S82Y-VK10F
41
35
±0.1
40
50
4.5 dia. ±0.1
35
25
10
7.3
t = 1.0
35
64
t = 2.0
80
60
±0.1
55
±0.1
13
4.5 dia.
±0.1
Left-side mounting Right-side mounting
25
±0.1
140
±0.1
150
38
4.5 dia.
±0.1
5.4
t = 2.0
240 W
Three locations
Mounting screw tightening
torque: 0.5 to 0.6 N·m
480 W
Four locations
Mounting screw tightening
torque: 0.5 to 0.6 N·m
Be sure to use the
accessory screws.
