S8VK-T
11
Mounting Brackets
Note: Be sure to use the accessory screws.
Mounting screw tightening torque (recommended): 4.43 to 5.31 lb-in (0.5 to 0.6 N·m)
* You can mount the side of the Power Supply to a DIN Rail by removing the DIN Rail Back-mounting Bracket and then attaching a Side-mounting
Bracket to the Power Supply.
Name Model Qty used
Front-mounting bracket (for 120, 240 and 480 W models) S82Y-VK10F 1
Front-mounting bracket (for 960 W model) S82Y-VK10F 2
Side-mounting bracket (for 120 W model) S82Y-VK10S 1
Side-mounting bracket (for 240 W model) S82Y-VK20S 1
Type Model Dimensions Appearance
Front-mounting
bracket
(for 120, 240,
480 W and 960 W
models)
S82Y-VK10F
Side-mounting
bracket
(For 120 W model)
S82Y-VK10S
Side-mounting
bracket
(For 240 W model)
S82Y-VK20S
38
150
140
±0.1
25
±0.1
4-4.5 dia.
±0.1
5.4
64
±0.1
t = 2.0
For 960W type
120 W model
960 W model
240 W model
140
±0.1
50
±0.1
15.5
±0.1
150125
73
4-4.5 dia.
±0.1
4940
t = 2.0
Left-side mounting Right-side mounting
Left-side mounting
(DIN Rail) *
Right-side mounting
(DIN Rail) *
140
±0.1
50
±0.1
15.5
±0.1
150125
73
59
40
4-4.5 dia.
±0.1
t = 2.0
Left-side mounting Right-side mounting
Left-side mounting
(DIN Rail) *
Right-side mounting
(DIN Rail) *
