Omron S8VK-T12024 - Connections; Block Diagrams

S8VK-T
5
Connections
Block Diagrams
Voltage
detection circuit
Photocoupler
Rectifier/
smoothing
circuit
L1
L2
INPUT
L3
Drive
control
circuit
+V
−V
DC OUTPUT
Overvoltage
detection circuit
Noise filter
lnrush
current
protection
Smoothing
circuit
Overcurrent
detection circuit
Rectifier
S8VK-T12024 (120 W)
S8VK-T24024 (240 W)
S8VK-T48024 (480 W)
S8VK-T96024 (960 W)
Voltage
detection circuit
Photocoupler
Rectifier/
smoothing
circuit
L1
L2
INPUT
L3
Drive
control
circuit
+V
−V
DC OUTPUT
Overvoltage
detection circuit
Noise filter
lnrush
current
protection
Smoothing
circuit
Overcurrent
detection circuit
Rectifier
