Omron S8VK-T12024 - Page 9

S8VK-T
9
Dimensions (Unit: mm)
117.8
(4)
112.2
(1)
(10)
6.35
6.35
19.8
4.7
(Sliding: 7.5 max.)Rail Stopper
40
±1
104.6 125±1
122.2±1
S8VK-T12024 (120 W)
104.6
(10)
6.35
4.7
(Sliding: 7.5 max.)
19.8
Rail Stopper
6.35
60
±1
125±1
145.6
(4)140
(1)
150
±1
S8VK-T24024 (240 W)
6.35 6.35
30 25
19.8
(26.8)
Rail Stopper
4.7
(Sliding: 7.5 max.)
(10)
125±1
145.6
(4)140
(1)
150
±1
52.3
95
±1
S8VK-T48024 (480 W)
10.16
47.9
10.16
170
175.6
4.7
(Sliding: 7.5 max.)
(10)
125±1
(4)
(1)
135
±1
41.78 32.95
19.8
(36.7)
Rail Stopper
180
±1
S8VK-T96024 (960 W)
