S8VS
7
Note: Refer to page 5 for notes 1 to 11.
Power ratings 240 W 480 W
Item Type Standard
Maintenance
forecast monitor
Total run time
monitor
Standard
Maintenance
forecast monitor
Total run time
monitor
Efficiency
With 100-VAC input 85% typical 89% typical
With 200-VAC input 88% typical 93% typical
Input
Voltage *1
100 to 240 VAC (allowable range: 85 to 264 VAC or 80 to 370 VDC
*
11)
100 to 240 VAC (allowable range: 85 to 264 VAC)
Frequency *1 50/60 Hz (47 to 63 Hz)
Current
With 100-VAC input 3.8 A max., 2.9 A typical 7.4 A max., 5.8 A typical
With 200-VAC input 2.0 A max., 1.5 A typical 3.9 A max., 2.8 A typical
Power factor 0.9 min. 0.95 min.
Harmonic current regulation Conforms to EN61000-3-2
Leakage current
With 100-VAC input 0.5 mA max.
With 200-VAC input 1.0 mA max.
Inrush current *2
With 100-VAC input 17.5 A max., 14 A typical
With 200-VAC input 35 A max., 28 A typical
Output
Voltage adjustment range *3 −10% to 15% (with V.ADJ) −10% to 15% (with V.ADJ)
Ripple noise voltage (at rated I/O) 140 mV max. 160 mV max. 310 mV max.
Input variation influence 0.5% max. (at 85- to 264-VAC input, 100% load)
Load variation influence
(rated input voltage)
1.5% max. (with rated input, 0 to 100% load)
Temperature variation influence 0.05%/°C max.
Startup time
(at rated I/O) *2
With 100-VAC input 540 ms typical 510 ms typical 550 ms typical
With 200-VAC input 230 ms typical 510 ms typical 550 ms typical
Output hold time
(at rated I/O) *2
With 100-VAC input 64 ms typical 46 ms typical 37 ms typical
With 200-VAC input 64 ms typical 46 ms typical 41 ms typical
Additional
functions
Overload protection *2
105% to 160% of rated load current, inverted L voltage drop,
automatic reset
151% to 165% of rated load current, inverted L voltage drop,
intermittent, automatic reset
Overvoltage protection *2, *4 Yes
Output voltage indication *5 No Yes (selectable) *6 No Yes (selectable) *6
Output current indication *5 No Yes (selectable) *7 No Yes (selectable) *7
Peak-hold current indication *5 No Yes (selectable) *8 No Yes (selectable) *8
Maintenance forecast monitor indication *5 No Yes (selectable) No Yes (selectable) No
Maintenance forecast monitor output No
Yes (transistor output),
30 VDC max., 50 mA
max.
*
9
No
Yes (transistor
output), 30 VDC
max., 50 mA max.
No
Total run time monitor indication *5 No Yes (selectable) No Yes (selectable)
Total run time monitor output *5 No
Yes (transistor output),
30 VDC max., 50 mA
max.
*
9
No
Yes (transistor output),
30 VDC max., 50 mA
max.
*
9
Undervoltage alarm indication *5 No Yes (selectable) No Yes (selectable)
Undervoltage alarm output terminals No
Yes (transistor output), 30 VDC max.,
50 mA max. *9
No
Yes (transistor output), 30 VDC max.,
50 mA max. *9
Parallel operation No (However, backup operation is possible. An external diode is required.)
Series operation Yes for up to 2 Power Supplies (with external diode)
Other
Operating ambient temperature Refer to the derating curve in . (with no icing or condensation)
Storage temperature −25 to 65°C
Operating ambient humidity 25% to 85% (Storage humidity: 25% to 90%)
Dielectric strength
3.0 kVAC for 1 min. (between all inputs and outputs/alarm outputs; detection current: 20 mA)
2.0 kVAC for 1 min. (between all inputs and PE terminals; detection current: 20 mA)
1.0 kVAC for 1 min. (between all outputs/ alarm outputs and PE terminals; detection current for standard 240-W and 480-W
models: 30 mA, detection current for 240-W models with indication monitor: 20 mA)
500 VAC for 1 min. (between all outputs and alarm outputs; detection current: 20 mA)
Insulation resistance 100 MΩ min. (between all outputs/ alarm outputs and all inputs/ PE terminals) at 500 VDC
Vibration resistance
10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions
10 to 150 Hz, 0.35-mm single amplitude (5 G max.) for 80 min each in X, Y, and Z directions: 240 W
10 to 150 Hz, 0.35-mm single amplitude (3 G max.) for 80 min each in X, Y, and Z directions: 480 W
Shock resistance 150 m/s
2
, 3 times each in ±X, ±Y, and ±Z directions
Output indicator Yes (color: green)
EMI
Conducted
Emissions
Models with indication monitor: Conforms to EN55011 Group1
Class A and based on FCC Class A, Conforms to EN55011
Group1 Class B *11
Standard models: Conforms to EN55011 Group1 Class B and
based on FCC Class A
Conforms to EN55011 Group1 Class A and based on FCC
Class A
Conforms to EN55011 Group1 Class B *11
Radiated Emissions
Models with indication monitor: Conforms to EN55011 Group1
Class A, Conforms to EN55011 Group1 Class B *11
Standard models: Conforms to EN55011 Group1 Class B
Conforms to EN55011 Group1 Class A
Conforms to EN55011 Group1 Class B *11
EMS Conforms to EN61204-3 high severity levels
Approved standards *11
UL 508 (Listing)
CSA C22.2 No.107.1 (cUL)
EN 62477-1
EAC mark, RCM mark, KOSHA S Mark *10
UL 508 (Listing)
UL 60950-1 (Recognition)
UL 62368-1 (Recognition)
CSA C22.2 No.107.1 (cUL)
CSA C22.2 No. 60950-1 (cUR), No. 62368-1 (cUR)
EN 50178 (=VDE 0160), EN 60950-1 (=VDE 0805 Teil 1)
EAC mark, RCM mark
SEMI *11 F47-0706 (200-VAC input)
Weight 1,150 g max. 1,700 g max.
