S8VS
Dimensions
Power Supplies with Screw Terminal Blocks
Note: All units are in millimeters unless otherwise indicated.
S8VS-015@@ (15 W)
S8VS-030@@ (30 W)
Five, M3.5 terminal screws
4.8
with square washers
(Sliding: 10 max.)
10
35.2
85
4
22.5
4.8
96.4
Rail stopper
(Sliding: 10 max.)
Note: The illustration is the S8VS-03024 model.
S8VS-06024 (60 W)
S8VS-06024A (60 W)
Five, M4 terminal screws
S8VS-06024B (60 W)
11.3
with square washers
97
10
35.4
74
95
1
40
4.5
108.3
Rail stopper
(Sliding: 15 max.)
Note: The illustration is the S8VS-06024A model.
S8VS-09024 (90 W) /S8VS-09024S (90 W) /S8VS-12024 (120 W)
S8VS-09024A@ (90 W) /S8VS-09024A@S (90 W) /S8VS-12024A@ (120 W)
S8VS-09024B@ (90 W) /S8VS-09024B@S (90 W) /S8VS-12024B@ (120 W)
S8VS-09024BE (90 W) /S8VS-09024BES (90 W) /S8VS-12024BE (120 W)
Five, M4 terminal screws
with square washers
10.8
110.5
10
35.4
94
115
1
50
4.5
121.3
Rail stopper
(Sliding: 15 max.)
Screwless block (2.5-mm pitches)
Note: The illustration is the S8VS-12024A model.
S8VS-18024 (180 W)
S8VS-18024A@ (180 W)
Seven, M4 terminal screws
125.3
with square washers
S8VS-18024B@ (180 W)
120.3
10
S8VS-18024BE (180 W)
35.4
94
115
75
4.5
Rail stopper
(Sliding: 15 max.)
Screwless block (2.5-mm pitches)
Note: The illustration is the S8VS-18024A model.
26

Omron S8VS Series Specifications

General

Output Power	60 W, 120 W, 240 W
Mounting	DIN Rail Mounting
Protection	Overcurrent protection, Overvoltage protection
Safety Standards	UL508, EN50178
Dimensions	22.5 x 90 x 100 mm
Output Voltage	24 VDC
