Omron S8VS Series User Manual

S8VS
S8VS-24024 (240 W)
Seven, M4 terminal screws
S8VS-24024A@ (240 W)
125.3
with square washers
S8VS-24024B@ (240 W)
120.3
100
S8VS-24024BE (240 W)
35.4
94
115
10
50
4.5 (Sliding: 15 max.)
Rail stopper
Screwless block (2.5-mm pitches)
Rail stopper
Note: The illustration shows the S8VS-24024A model.
S8VS-48024 (480 W)
127.2
Nine, M4 terminal screws with square washers
S8VS-48024A (480 W)
123.8
150
S8VS-48024B (480 W)
35.4
115
93
115
10
4.5 (Sliding: 15 max.)
Rail stopper
70
Rail stopper
Screwless block (2.5-mm pitches)
Note: The illustration shows the S8VS-48024A model.
Power Supplies with Screwless Terminal Blocks
S8VS-06024-F (60 W)
10.2
S8VS-06024A-F (60 W)
97.1
10
S8VS-06024B-F (60 W)
35.4
77.4 95
1
40
107.3
4.5 (Sliding: 15 max.)
Rail stopper
Note: The illustration shows the S8VS-06024-F model.
S8VS-09024-F (90 W) /S8VS-09024S-F (90 W) /S8VS-12024-F (120 W)
S8VS-09024A@-F (90 W) /S8VS-09024A@S-F (90 W ) /S8VS-12024A@-F (120 W)
S8VS-09024B@-F (90 W) /S8VS-09024B@S-F (90 W) /S8VS-12024B@-F (120 W)
S8VS-09024BE-F (90 W) /S8VS-09024BES-F (90 W) /S8VS-12024BE-F (120 W)
10
10
110.3
35.4 97.3 115
1
50
4.5 (Sliding: 15 max.)
120.3
Rail stopper
Note: The illustration shows the S8VS-12024-F model.
27

Omron S8VS Series Specifications

General

Output Power	60 W, 120 W, 240 W
Mounting	DIN Rail Mounting
Protection	Overcurrent protection, Overvoltage protection
Safety Standards	UL508, EN50178
Dimensions	22.5 x 90 x 100 mm
Output Voltage	24 VDC
