Omron S8VS Series User Manual

S8VS
S8VS-06024-@ (60 W)
Fuse
6.3 A
AC (L)
INPUT
Noise filter
AC (N)
Rectifier
Inrush current
Smooth-
Voltage
detection circuit
Photocoupler
Rectifier/smoothing circuit
Drive control
circuit
Overcurrent
Current detection
circuit
circuit
Overvoltage
detection circuit
protection
circuit
ing
circuit
+V
DC OUTPUT
−V
S8VS-09024A@ (90 W)
S8VS-09024B@ (90 W)
Sinking type (S8VS-09024A, S8VS-09024B) Sourcing type (S8VS-09024AP, S8VS-09024BP)
+V
−V
Voltage
detection circuit
Photocoupler
Photocoupler
Rectifier/smoothing circuit
Rectifier/smoothing circuit
Rectifier/
smoothing
circuit
Noise filter
AC (L)
INPUT
AC (N)
Drive control
circuit
Alarm
DC Low
Yrs/kh
Common
DC OUTPUT
Fuse 4.0 A
Overcurrent
circuit
Arithmetic
operation circuit
Display circuit Switch
Overvoltage
detection circuit
Current detection
circuit
Rectifier/smoothing circuit
Arithmetic
operation circuit
Display circuit Switch
Photocoupler
Alarm
DC Low
Yrs/kh
Common
Inrush current
protection
circuit
S8VS-09024A-F (90 W)
S8VS-09024B-F (90 W)
S8VS-09024AS-@ (90 W)
S8VS-09024BS-@ (90 W)
S8VS-09024AP-F (90 W)
S8VS-09024BP-F (90 W)
S8VS-09024APS-@ (90 W)
S8VS-09024BPS-@ (90 W)
S8VS-09024BE-@ (90 W)
S8VS-09024BES-@ (90 W)
Fuse 8.0 A
AC (L)
INPUT
AC (N)
Switch
Rectifier
+V
−V
Voltage
detection circuit
Photocoupler
Photocoupler
Rectifier/smoothing circuit
Rectifier/
smoothing
circuit
Noise filter
Drive control
circuit
Alarm
DC Low
Yrs/kh
Common
DC OUTPUT
Overcurrent
circuit
Arithmetic
operation circuit
Display circuit
Overvoltage
detection circuit
Current detection
circuit
Inrush current
protection
circuit
Sinking type
(S8VS-09024A-F, S8VS-09024B-F,
S8VS-09024AS-@, S8VS-09024BS-@)
Rectifier/smoothing circuit
Sourcing type
(S8VS-09024AP-F, S8VS-09024BP-F,
S8VS-09024APS-@, S8VS-09024BPS-@)
Rectifier/smoothing circuit
Arithmetic
operation circuit
Display circuit Switch
Photocoupler
Alarm
DC Low
Yrs/kh
Common
Type with no alarm output
(S8VS-09024BE-@, S8VS-09024BES-@)
Rectifier/smoothing circuit
Arithmetic
operation circuit
Display circuit Switch
9

Omron S8VS Series Specifications

General

Output Power	60 W, 120 W, 240 W
Mounting	DIN Rail Mounting
Protection	Overcurrent protection, Overvoltage protection
Safety Standards	UL508, EN50178
Dimensions	22.5 x 90 x 100 mm
Output Voltage	24 VDC
