2) LUMINANCE
Sets the target Brightness for the “normal” and “long” auto exposure and the auto gain operation.
The brightness image maintains with the auto exposure and the auto gain operation.
Setting range: 0 (Dark) to 65,535 (Bright)
Default: 4,608
3) PRI GAIN
Sets the fixed gain for the “normal” and the “long” auto exposure and the auto gain operation.
Please sets “OFF” for the auto gain operation.
Setting selection: OFF / 1.2 dB / 3.31 dB / 5.12 dB / 6.92 dB / 9.33 dB / 11.14 dB / 12.94 dB /
15.34 dB / 17.16 dB / 18.96 dB / 21.37 dB / 24.0 dB / 27.09 dB / 29.2 dB
Default: OFF
4) PRI SHUTTER
Sets the exposure time for the “normal” and the “long” auto exposure and the auto gain operation.
Please sets “OFF” for the auto shutter operation.
Setting selection: OFF / 1/10,000 seconds (0.0001 seconds) to 2.55 seconds
Default: OFF
5) USER GAIN
Sets the fixed gain for the “USER MODE” exposure and gain operation.
Setting range: 1.2 dB to 46.2 dB
Default: 1.2 dB
6) USER SHUTTER
Sets the exposure time for the “USER MODE” exposure and gain operation.
Setting range: 1/10,000 seconds (0.0001 seconds) to 2.55 seconds
Default: 1/100 seconds (0.01 seconds)
7) GAMMA
Sets the Gamma.
It is necessary to set the manual gamma setting with the PC communication.
Setting selection: MANUAL, 0.45, 0.60, 0.80, 1.00
Default: MANUAL.
