Omron STC-HD203 Series - Page 64

No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
64/78
Page 2
1) WB MODE
Selects the white balance mode from below four modes. (Default: AWB).
a) AWB
The auto white balance.
b) FULL OPEN
The full pull-in frame. As for the detail, please refer to the another chapter.
b) AWB HOLD
Hold the current white balance settings.
b) USER MODE
The manual white balance with “USER R/G” R gain and “USER B/G” B gain.
2) USER R/G
Sets the R/G gain for “USER MODE” white balance.
Setting range: 0 to 65,535
Default: 2,453
3) USER B/G
Sets the B/G gain for “USER MODE” white balance.
Setting range: 0 to 65,535
Default: 7,295
4) OFFSET
Sets the offset of the image.
Setting range: 0 to 127
Default: 0
5) CONTRAST
Sets the contrast of the image.
Setting range: 0 to 128
Default: 128
PAGE 1 2 3 4 5 6
WB MODE AWB
USER R/G 00000
USER B/G 00000
OFFSET 000
CONTRAST 128
SHARPNESS H04 V06 COR03
