b) H SIZE
Sets the size (thickness) for the horizontal line 1.
Setting range: 0 (0 line, no horizontal line) to 1,080 (1,080 lines)
Default: 0
c) H COLOR
Sets the color for the horizontal line 1.
It is necessary to set the USER0 to USER7 colors with the PC communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
d) V POS
Sets the position for the vertical line 1.
Setting range: 0 (Left end) to 1,920 (Right end)
Default: 0
e) V SIZE
Sets the size (thickness) for the vertical line 1.
Setting range: 0 (0 pixel, no vertical line) to 1,920 (1,920 pixels)
Default: 0
F) V COLOR
Sets the color for the vertical line 1.
It is necessary to set the USER0 to USER7 colors with the PC communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
4) Horizontal line 2 maker and vertical line 2 maker settings
Sets the color, the size (thickness) and the position for the horizontal line 2 and the vertical line 2.
a) H POS
Sets the position for the horizontal line 2.
Setting range: 0 (Top) to 1,080 (Bottom)
Default: 0
b) H SIZE
Sets the size (thickness) for the horizontal line 2.
Setting range: 0 (0 line, no horizontal line) to 1,080 (1,080 lines)
Default: 0
c) H COLOR
Sets the color for the horizontal line 2.
It is necessary to set the USER0 to USER7 colors with the PC communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
