No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
69/78
Page 4
1) GRAPHICS
Selects enable or disable for the line makers and the shadow mask. (Default: ON).
This function in the page3 and in the page4 is the same function.
2) SHADOW
Selects enable or disable for the Shadow mask display (Default: ON).
This setting is only valid when “GRAPHICS” is “ON”.
a) ON
The shadow mask can be display.
Sets the grade and the position for the shadow mask.
b) OFF
The shadow mask does NOT display.
3) Shadow mask settings
a) GRADE
Sets the grade of the shadow mask.
Setting range: 0 (No grade, the image is visible) to 255 (Back)
Default: 0
b) SHADOW H T
Sets the position for the top area of the shadow mask.
Setting range: 0 (Top) to 1,079 (Bottom)
Default: 0
c) SHADOW H B
Sets the position for the bottom area of the shadow mask.
Setting range: 0 (Top) to 1,080 (Bottom)
Default: 0
d) SHADOW V L
Sets the position for the left area of the shadow mask.
Setting range: 0 (Left) to 1,919 (Right)
Default: 0
PAGE 1 2 3 4 5 6
GRAPHICS ON
SHADOW ON GRADE 000
H T 0000 B 1020
V L 0000 R 1280
CIRCLE ON
RADIUS 000 SIZE 000
H POS 0960
V POS 0540
COLOR BLACK
