e) SHADOW V R
Sets the position for the right area of the shadow mask.
Setting range: 0 (Left) to 1,920 (Right)
Default: 0
Shadow mask
Vertical line 1 Vertical line 2
Horizontal line 1
Horizontal line 2
LINE1 V POS
LINE2 V POS
LINE1 H POS
LINE2 H POS
SHADOW H T
SHADOW H B
SHADOW V L
SHADOW V R
