No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
71/78
4) CIRCLE
Selects enable or disable for the circle maker display (Default: ON).
This setting is only valid when “GRAPHICS” is “ON”.
a) ON
The circle maker can be display.
Sets the radius, the line size (thickness), the center position and the color for the circle maker.
b) OFF
The circle maker does NOT display.
5) Circle maker settings
Sets the radius, the size (thickness), the center position and the color for the circle maker.
a) RADIUS
Sets the radius for the circle.
Setting range: 000 (Filled circle) to 960
Default: 000
b) SIZE
Sets the size (thickness) for the circle.
Setting range: 0 (0, no circle) to 480
Default: 000
c) H POS
Sets the horizontal center position for the circle.
Setting range: 000 (Left end) to 1,920 (Right end)
Default: 960
d) V POS
Sets the vertical center position for the circle.
Setting range: 000 (Top) to 1,080 (Bottom)
Default: 540
e) COLOR
Sets the color for the circle.
It is necessary to set the USER0 to USER7 colors with the PC communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
