1-3
D 3G3HV Series
Voltage class Protective structure Maximum applied motor capacity Model
200-V class NEMA1 type
0.4 kW 3G3HV-AB004-CE
(single phase)
0.75 kW 3G3HV-AB007-CE
1.5 kW 3G3HV-AB015-CE
2.2 kW 3G3HV-AB022-CE
3.7 kW 3G3HV-AB037-CE
400-V class NEMA1 type
0.4 kW 3G3HV-A4004-CUE
(3-phase)
0.75 kW 3G3HV-A4007-CUE
1.5 kW 3G3HV-A4015-CUE
2.2 kW 3G3HV-A4022-CUE
3.7 kW 3G3HV-A4037-CUE
5.5 kW 3G3HV-A4055-CUE
7.5 kW 3G3HV-A4075-CUE
11 kW 3G3HV-A4110-CUE
15 kW 3G3HV-A4150-CUE
Open chassis type
18.5 kW 3G3HV-B4185-CUE
22 kW 3G3HV-B4220-CUE
30 kW 3G3HV-B4300-CUE
37 kW 3G3HV-B4370-CUE
45 kW 3G3HV-B4450-CUE
55 kW 3G3HV-B4550-CUE
75 kW 3G3HV-B4750-CUE
110 kW 3G3HV-B411K-CUE
160 kW 3G3HV-B416K-CUE
H Conformance to the LVD (Low-voltage Directives) and EMC Directives
The SYSDRIVE CUE (CE) models conform to the LVD (prEN50178) and the EMC (EN50081-2,
EN50082-2) Directives.
However, when the product is built into a unit, the connected switches, optional items, or motors may not
satisfy these standards. In such a case, either use components that meet the standards or take ap-
propriate countermeasures such as providing surge killers or other noise prevention devices.
H Conformance Conditions
There are several conditions that must be satisfied for this Inverter to conform to the LVD and EMC
Directives. To satisfy the standards, meet the instructions in this manual for the following installation
conditions. If the Inverters are used beyond the conditions specified here, final confirmation must be
made on the overall units.
• Installation of noise filters.
• Shield stranded cables must be used for input and output cables.
Limitations on the lengths of cables.
• Installation of metallic ground plates.
• Installation of recommended fuses on the input side.
Introduction Chapter 1
