3-6
3-2 Input Noise Filter Specification
Noise Filter List for EMC Directives
Inverter model
Noise filter (manufactured by Schaffner)
3G3FV/3G3HV
Model Rated current (A) Weight (kg) Dimensions
(W×D×H) (mm)
A4004-CUE
3G3FV-PFS4874-7-07 7 1.1 50×126×255
A4007-CUE
A4015-CUE
A4022-CUE
3G3FV-PFS4874-18-07 18 1.7 55×142×305
A4037-CUE
A4055-CUE
3G3FV-PFS4874-30-07 30 2.0 60×150×335
A4075-CUE
A4110-CUE
3G3FV-PFS4874-42-07 42 3.0 70×185×329
A4150-CUE
B4185-CUE 3G3FV-PFS4874-55-07 55 3.3 80×185×329
B4220-CUE
3G3FV-PFS4874-75-34 75 4.3 80×220×329
B4300-CUE
B4370-CUE 3G3FV-PFS4874-100-35 100 5.7 90×220×379
B4450-CUE 3G3FV-PFS4874-130-35 130 8.0 110×240×439
B4550-CUE 3G3FV-PFS4874-180-07 180 11 110×240×438
B4750-CUE 3G3FV-PFS4874-300-99 300 15 300×564×160
B411K-CUE
3G3FV-PFS4874-400-99 400 22 300×564×160
B416K-CUE
AB004-CE 3G3HV-PFS4971-10-07 10 0.7 57.5×156×45.4
AB007-CE
3G3HV-PFS4971-20-07 20
1.0 85.5×119×57.6
AB015-CE
AB022-CE
3G3HV-PFS4971-40-07 40
3.0 90×246×65
AB037-CE
Specifications Chapter 3
