3-7
External Dimensions of Input Noise Filters
D 3G3FV-PFS4874-7-07 to PFS4874-55-07
Model 3G3FV- A B C E F G H J K L
PFS4874-7-07 255 240 225 300±10 9 50 25 6.5 M5 126
PFS4874-18-07 305 290 275 300±10 9 55 30 6.5 M5 142
PFS4874-30-07 335 320 305 400±10 9 60 35 6.5 M5 150
PFS4874-42-07 329 314 300 500±10 12 70 45 6.5 M6 185
PFS4874-55-07 329 314 300 500±10 12 80 55 6.5 M6 185
Specifications Chapter 3
