4-8SectionOffset and Gain Adjustment
101
The procedure for adjusting the analog output gain is explained below. As shown
in the following diagram, the set value is adjusted so that the analog output is
maximized (to 10V/5V/20mA).
10 V
0
0FA0
Output signal range:
0 to 10 V
Gain adjustment output range
The following example uses output number 1 adjustment for illustration. (The
unit number is 0.)
1, 2, 3... 1. Turn ON bit 01 (the Gain Bit) of IR word n+1. (Hold the ON status.)
CLR
00000
SHIFT
CONT
#
1
B
0
A
1
B
0
A
1
B
MONTR
10101
^OFF
PLAY
SET
10101
ON
2. Check whether the output devices are connected.
A0
A1
A2
A3
A0
A1
A2
A3
Voltage output
Current output
Output 1
Output 1
Gain Adjustment
To Next Page
