Omron SYSMAC CJ1W-SCU21-V1 User Manual

87
I/O Memory Allocations Section 2-3
No-protocol Mode Bits
Serial Communications
Units (CS/CJ Series)
Port 1 and Port 2 Port Settings Change Bits
These bits can be turned ON from the program using the OUT or other
instructions to change communications settings and restart the Serial Com-
munications Unit ports. When changing the settings and restarting the port
have been completed, the bit will automatically be turned OFF. The port 1 or
port 2 Port Settings Change Bits and Restart Bits are allocated in the Auxiliary
Area according to the unit number as shown below.
Note These bits are used both to change the port settings and to restart the port at
the same time. One of these bits can be turned ON to restart a port without
changing the port settings in the Setup Area allocated in the DM Area. The
STUP(237) instruction can also be used to just restart a communications port
by executing STUP(237) with the same port settings as the ones already
being used.
n = A620 + unit number
Boards (CS Series only) Contents
Port 1 Port 2
Word Bit Word Bit
A356 07 A356 15 Reception Overflow Flag
1: Board/Unit has received the specified
number of bytes or more
0: Board/Unit has not received the speci-
fied number of bytes or more
06 14 Reception Completed Flag
1: Reception completed; 0: No reception
or reception in progress
05 13 Send Ready Flag
1: Send enabled; 0: Send disabled
00 to 04 08 to 12 Reserved
A357 00 to 15 A358 00 to 15 Receive counter (number of receive data
bytes)
The number of bytes of received data
between 0 and 256 bytes is indicated
using 0000 to 0100 hex.
Words Bit Contents
n 03 to 15 Reserved
02 1: Port 2 Settings Change Bit
01 1: Port 1 Settings Change Bit
00 Reserved
Unit Port 1 Settings Change Bit Port 2 Settings Change Bit
Unit No. 0 A62001 A62002
Unit No. 1 A62101 A62102
Unit No. 2 A62201 A62202
Unit No. 3 A62301 A62302
Unit No. 4 A62401 A62402
Unit No. 5 A62501 A62502
Unit No. 6 A62601 A62602
Unit No. 7 A62701 A62702
Unit No. 8 A62801 A62802
Unit No. 9 A62901 A62902
