Omron SYSMAC CJ1W-SCU21-V1 User Manual

391
CompoWay/F Master Protocol Appendix B
Operation Command
(Sequence No. 621 (Hex 026D))
This sequence remotely stops/starts operations of the device at the specified node number.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0
Number of send data words 0004 to 00FA Hex (4 to 250 decimal)
+1
(Undefined)
(00 hex)
Node No.
(2 digits BCD)
00 to 99
+2
Number of bytes to send
(4 digits hex)
Set the number of send bytes for
related information (Set to 0002 hex
when there is no related information.)
+3
Command code
(2 digits hex)
Set the command code and related
information.
+4
Related information
First word of
send data
Number of send data words
+0
+1
(Undefined)
Node No.
Number of send data bytes
+2
Related information
+4
+3
Command code
Offset Contents (data format) Data
+0
Number of receive data words 0003 to 00FA hex (3 to 250 decimal)
+1
Response code (4 digits hex) The CompoWay/F command response
code is stored in hexadecimal code.
+2
Command code
(4 digits hex)
The command code and related infor-
mation are stored.
+3
Related information
Receive data
storage words
+0
+1
+2
Command code
Number of receive data words
Response code
Related information
