Omron SYSMAC CJ1W-SCU21-V1 User Manual

662
3Z4L Laser Micrometer Protocol Appendix N
Note This sequence can be used for the 3Z4L-4000 Series only when pin 8 on DIP switch SW2 is turned ON.
Single Run Measurement Start (4000-series) (Sequence No. 434
(Hex 01B2))
When the sample measurement condition is from 1 to 999, this sequence performs a single run measurement
and requests the measurement results.
Send Data Word Allocation (3rd Operand of PMCR(260))
None.
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of receive data
words (4 digits Hex)
0013 (0019 decimal) (fixed)
+1 Segment number
(1 digit BCD)
1 to 5
+2 Measurement interval num-
ber (1 digit BCD)
1 to 7
+3 Lower limit value (Decimal
portion)
(4 digits BCD)
0000 to 9999
+4 Lower limit value (Integer
portion)
(3 digits BCD)
000 to 999
+5 Lower limit value (Sign)
(BIN)
If +: 0
If –: F
+6 to +8 Upper limit value Same as lower limit value
+9 to
+11
Reference value Same as lower limit value
+12 Analog output scale number
(1 digit BCD)
0 to 3
+13 to
+15
Forced zero number (ASCII
5 characters)
5A45524F2B (“ZERO+”)
4E4F524D20 (“NORM ”)
5A45524F2D (“ZERO–”)
+16 Data output condition
(1 digit BCD)
0 to 6
+17 Data output timer value
(3 digits BCD)
000 to 999
+18 Number of seconds for latch
timer
(2 digits BCD)
00 to 99
4 5 6 7
0 1 2 3
F 0 0 0
+3
+4
+5
Example –123.4567
Receive data
storage words
Number of receive data words
+0
+1
+2
+3
+4
+5
+6
+7
Decimal portion
(Undefined) Integer portion
Sign (Undefined)
Decimal portion
(Undefined) Integer portion
Sign (Undefined)
Decision result
Measurement value
Deviation value
