Omron SYSMAC CJ1W-SCU21-V1 User Manual

675
Visual Inspection System Protocol Appendix O
Evaluation Condition Change (F200)
(Sequence No. 456 (Hex 01C8))
This sequence changes the upper and lower limit values of evaluation condition of the designated output No.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note 1. Only one output No. can be designated.
2. Enter values so that upper limit
≥ lower limit.
3. Enter upper limit and lower limit values within the range –2147483.648 to 2147483.648.
Arbitrary Measurement Value Acquisition (F200)
(Sequence No. 457 (Hex 01C9))
This sequence stores measurement values of arbitrary measurement items regardless of output format in the
specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Content (data format) Data
+0 Number of send data words
(4 digits Hex)
000A (0010 decimal)
+1 Output No. (2 digits BCD) 00 to 07
+2 to +5 Upper limit value (decimal portion)
(3 digits BCD)
Upper limit value (integer portion)
(7 digits BCD)
Upper limit value (sign) (ASCII 2 digits)
+6 to +9 Lower limit value (decimal portion)
(3 digits BCD)
Same as upper limit.
Lower limit value (integer portion)
(7 digits BCD)
Lower limit value (sign) (ASCII 2 digits)
Integer portion
First word of send
data
Number of send data words
+0
+1
+2
+3
+4
+5
+6
+7
+8
+9
(Undefined)
Output No.
(Undefined)
Upper limit value
Decimal portion
(Undefined)
Sign
(Undefined)
Integer portion
(Undefined)
Lower limit value
Decimal portion
(Undefined)
Sign (Undefined)
Example
–123.456
+2
+3
+4
+5
0567
1234
Example
+123.456
+2
+3
+4
+5
0678
2345
0000 0001
2D00 3000
First word of
send data
Number of send data words
+0
+1
+2
(Undefined)
Data 1
(Undefined)
Data 2
