3Z4L Laser Micrometer Protocol Appendix N
• DIP Switch 3
3Z4L-4000 Series
• DIP Switch 1
• DIP Switch 2
No. Setting Status
1 Setting of measurement
function by 2 measure-
ment instruments
ON/OFF
2ON/OFF
3ON/OFF
4ON/OFF
5 Error data exclusion func-
tion
ON/OFF
6 Multistep selection func-
tion
ON/OFF
No. Setting Status
1 Baud rate ON/OFF
2ON/OFF
3 Hand-shake procedure ON/OFF
4 Delimiter ON/OFF
5ON/OFF
6 RS-232C interface use
selection
ON/OFF
7ON/OFF
8ON/OFF
No. Setting Status
1 Selection for measure-
ment section
ON/OFF
2ON/OFF
3ON/OFF
4ON/OFF
5 Setting of minimum read
value
ON/OFF
6ON/OFF
7 Display unit ON/OFF
8 External command setting ON/OFF
This protocol does not sup-
port the error data exclusion
function
Set these settings according
to the sensor connected.
Set these settings for
4 digits in the decimal por-
tion.
To Next Page
