7 Serial Communications
7 - 16
NX-series Communications Interface Units User’s Manual (W540)
In this example, the following 26-byte text string is received: ABCDEFGHIJKLMNOPQRSTUVWXYZ.
The text string is separated into
the first 20 bytes (ABCDEFGHIJKLMNOPQRST) and the remaining 6
bytes (UVWXYZ) to send it from the CIF Unit to the CPU Unit or communications master.
It is assumed that the Number of Characters to Determine the End is set
as the condition to determine
the reception completion.
For a programming sample for this example, refer to A-4-4 Programming Sample 3: Receiving Data on
pag
e A-38.
Here, we will assume that the input notification data and output notification data are in the following sta-
tu
s before the data is received.
 Input Notification Data
 Output No
tification Data
7-4-2 Example of Receiving Data
NX object name Value
Port Status 0010 hex
Input SID 00 hex
Output SID Response 02 hex
Input Data Type 0000 hex
Input Sub Info 0000 hex
Input Data Length 0000 hex
Input Data 01 to 05 00 hex, 00 hex ...
NX object name Value
Output SID 02 hex
Input SID Response 00 hex
Output Data Type 0000 hex
Output Sub Info 0000 hex
Output Data Length 0000 hex
Output Data 01 00 hex, 00 hex, 00 hex, 00 hex
Step Process
CPU Unit or communications master
processing
Communi-
cations
direc
tion
*1
CIF Unit processing
1 Receiving
A to Z
--- Th
e CIF Unit receives ABCDEFGHIJKLM-
NOPQRSTUVWXYZ from the serial line.
