Omron V7

6
Frequency inverters
IIP65 type 0.55 to 4 Kw
Voltage
class
Max.
applicable
motor
output kW
Inverter
model
CIMR V7TZ
Figure
Dimensions in mm
Weight
kg
Cooling
method
W H D W1 W2 H1 H2 H3 D1
Single-phase
200 V
0.55 B0P405
4
280 240 142 260 228 165 38 275 44
3.4 Self cooled
1.1 B0P705 4.3
Fan cooled1.5 B1P505 3.7
2.2 B2P205 4.2
Three-phase
400 V
0.55 40P405
280 240 142 260 228 165 38 275 44
4.2 Self cooled
1.1 40P705 4.3
Fan cooled
1.5 41P505 3.7
2.2 42P205 3.7
3.0 43P005 4.1
4.0 44P005 4.1
W 1
D
D1
W
H 2
H 1
H
Figure 4
W 2
H 1
6 . 4
3x PG25
Varispeed V7
7
IP65 type 0.55 to 4Kw (with option frame accessory attached)
Voltage
class
Max.
applicable
motor
output kW
Inverter
model
CIMR V7TZ
Figure
Dimensions in mm
Weight
kg
Cooling
method
W H D W1 W2 H1 H2 H3 D1 D2
Single-
phase 200 V
0.55 B0P405
5
280 240 180 260 228 165 38 275 44 38
3.6 Self cooled
1.1 B0P705 4.5
Fan cooled1.5 B1P505 3.9
2.2 B2P205 4.4
Three-phase
400 V
0.55 40P405
280 240 180 260 228 165 38 275 44 38
4.4 Self cooled
1.1 40P705 4.5
Fan cooled
1.5 41P505 3.9
2.2 42P205 3.9
3.0 43P005 4.3
4.0 44P005 4.3
Figure 5
W 2
D
D1
H 1
H
D2
W
W 1
6 . 4
H 2
H 1
3x PG25
2x PG12
