Omron V7 User Manual

6
Frequency inverters
IIP65 type 0.55 to 4 Kw
Voltage
class
Max.
applicable
motor
output kW
Inverter
model
CIMR V7TZ
Figure
Dimensions in mm
Weight
kg
Cooling
method
W H D W1 W2 H1 H2 H3 D1
Single-phase
200 V
0.55 B0P405
4
280 240 142 260 228 165 38 275 44
3.4 Self cooled
1.1 B0P705 4.3
Fan cooled1.5 B1P505 3.7
2.2 B2P205 4.2
Three-phase
400 V
0.55 40P405
280 240 142 260 228 165 38 275 44
4.2 Self cooled
1.1 40P705 4.3
Fan cooled
1.5 41P505 3.7
2.2 42P205 3.7
3.0 43P005 4.1
4.0 44P005 4.1
W 1
D
D1
W
H 2
H 1
H
Figure 4
W 2
H 1
6 . 4
3x PG25
Varispeed V7
7
IP65 type 0.55 to 4Kw (with option frame accessory attached)
Voltage
class
Max.
applicable
motor
output kW
Inverter
model
CIMR V7TZ
Figure
Dimensions in mm
Weight
kg
Cooling
method
W H D W1 W2 H1 H2 H3 D1 D2
Single-
phase 200 V
0.55 B0P405
5
280 240 180 260 228 165 38 275 44 38
3.6 Self cooled
1.1 B0P705 4.5
Fan cooled1.5 B1P505 3.9
2.2 B2P205 4.4
Three-phase
400 V
0.55 40P405
280 240 180 260 228 165 38 275 44 38
4.4 Self cooled
1.1 40P705 4.5
Fan cooled
1.5 41P505 3.9
2.2 42P205 3.9
3.0 43P005 4.3
4.0 44P005 4.3
Figure 5
W 2
D
D1
H 1
H
D2
W
W 1
6 . 4
H 2
H 1
3x PG25
2x PG12
Varispeed V710

Omron V7 Specifications

General

Series	V7
Cooling Method	Forced air cooling
Power Rating	0.4kW to 15kW
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
