352 Frequency inverters
Type designation
Specifications
Voltage class 200 V single/three-phase 400 V three-phase
Model CIMR-J7AZ#
Three-phase 20P1 20P2 20P4 20P7 21P5 22P2 24P0 40P2 40P4 40P7 41P5 42P2 43P0 44P0
Single-phase
1
1. Single-phase series inverter output is three-phase (for three-phase motors)
B0P1B0P2B0P4B0P7B1P5–––––––––
Max. applicable
motor output kW (HP)
2
2. Based on a standard 4-pole motor for max. applicable motor output. Select the inverter model whose rated current is larger than motor rated current.
0.12 0.25 0.55 1.1 1.5 2.2 4.0 0.37 0.55 1.1 1.5 2.2 3.0 4.0
Output
characteristics
Inverter capacity kVA
0.3 0.6 1.1 1.9 3.0 4.2 6.7 0.9 1.4 2.6 3.7 4.2 5.5 7.0
Rated output current A
0.8 1.6 3 5 8 11 17.5 1.2 1.8 3.4 4.8 5.5 7.2 9.2
Max. output voltage V
3-phase, 200 to 230 V (proportional to input voltage)
Single-phase, 200 to 240 V (proportional to input voltage)
3-phase, 380 to 460 V (proportional to input voltage)
Max. output frequency
400 Hz (programmable)
Power
supply
Rated input voltage
and frequency
3-phase, 200 to 230 V, 50/60 Hz
Single-phase, 200 to 240 V, 50/60 Hz
3-phase, 380 to 460 V, 50/60 Hz
Allowable voltage
function
–15 to +10%
Allowable frequency
function
±5%
Voltage
B: Single-phase 200 VAC
2: Three-phase 200 VAC
4: Three-phase 400 VAC
Z: European standard
specifications
Inverter
J7 series
A: With digital operator (with potentiometer)
CIMR—J7AZ20P1
Max. applicable motor output
0P1: 0.1 kW
4P0: 4.0 kW
~
"P" indicates a decimal
point
[ ]
