Omron VARISPEED J7 - Main Circuit; Control Circuit

Varispeed J7 359
Main circuit
Control circuit
Terminal Name Function (signal level)
R/L1, S/L2, T/L3
AC power supply input
Main circuit power supply input (Use R/L1 and S/L2 for single-phase power supply inverter.
Do not use T/L3 of the models less than 0.75kW for other usage, such as a junction terminal.)
U/T1, V/T2, W/T3
Inverter output
For inverter output
+2, +1
DC reactor connection
Remove the short bar between +2 and +1 when connecting DC reactor (option)
+1, –
DC power supply input
For power supply input (+1: positive electrode; – : negative electrode)*
Grounding
For grounding (grounding should conform to the local grounding code.)
Type No. Signal name Function Signal level
Digital input signals
S1
Multi-function input selection 1 Factory setting: runs when CLOSED, stops when OPEN. 24VDC, 8mA
photocoupler
isolation
S2
Multi-function input selection 2 Factory setting: runs when CLOSED, stops when OPEN.
S3
Multi-function input selection 3 Factory setting: "fault reset"
S4
Multi-function input selection 4 Factory setting: "external fault (NO contact)"
S5
Multi-function input selection 5 Factory setting: "multi-step speed reference 1"
SC
Multi-function input selection
common
Common for control signal
Analog
input
signals
FS
Power supply terminal for
frequency setting
+12V (allowable current: 20 mA max.)
FR
Speed frequency reference 0 to +10 VDC (20 kΩ) or 4 to 20 mA (250 Ω), 0 to 20 mA (250 Ω) (resolution 1/1000)
FC
Frequency reference common 0 V
Digital
output
signals
MA
NO contact output Factory setting: "running" Contact capacity
250 VAC, 1A or less
30 VDC, 1A or less
MB
NC contact output
MC
Contact output common
Analog
output
signals
AM
Analog monitor output Factory setting: "output frequency" 0 to +10 V output 0 to 10 V 2 mA or less
Resolution: 8bits
AC
Analog monitor common 0 V
