Omron VARISPEED J7 - Page 5

Varispeed J7 355
IP 20 type 0.1 to 4 kW
Dimensions
Voltage class
Max. applicable
motor output kW
Inverter model
CIMR-J7AZ#
Figure
Dimensions in mm
Weight kg
Cooling
method
W H D W1 H1 H2
200 V
three-phase
0.12
20P1
1 68 128 70 56 118 5 0.5 Self cooled
0.25
20P2
7.7
0.55
20P4
102 0.8
1.1
20P7
122 0.9 Fan cooled
1.5
21P5
2 108 129 96 118 1.3
2.2
22P2
154 1.5
4.0
24P0
140 161 128 2.1
200 V
single-phase
0.1
B0P1
1 68 128 70 56 118 5 0.5 Self cooled
0.2
B0P2
0.4
B0P4
112 0.9
0.75
B0P7
2 108 129 96 1.5 Fan cooled
1.5
B1P5
154
400 V
three-phase
0.37
40P2
2 108 128 81 96 118 5 1.0 Self cooled
0.55
40P4
99 1.1
1.1
40P7
129 1.5
1.5
41P5
154
2.2
42P2
Fan cooled
3.0
43P0
140 161 128 2.1
4.0
44P0
8.5
(0.34)
8.5
(0.34)
2 – M 4
4 – M 4
Figure 1 Figure 2
