224
Frequency Inverters
C PLC Option Card
D Option Frame accessory for V7 IP65
E Accessories
Type Model
1
1. Option frame accessory is needed on V7 IP65 types when PLC option unit is used.
Description Function
PLC option
3G3MV-P10CDT-E
3G3MV-P10CDT3-E
PLC option
Full PLC featrues, wireless installation and seamless access to the inverter parameters and
analogue/digital inputs and outputs.
Standard Omron tools can be used for programming
Calendar / Clock
PLC option with RS 422/485
Same features than standard models with RS 422/485 support.
Type Model Description Function
Option frame
V7TZ-FR1
Option Frame
Frame accessory is needed when communication option unit or PLC option unit are used
with Varispeed V7 IP65.
Types Model Description Funtions
Digital operator
JVOP-146
Remote digital operator
without potentiometer
JVOP-144
Remote digital operator
with potentiometer
72606-CVS31060 Blank cover -----
3G3IV-PEZZ0838BA Digital operator case same as JVOP-144 without operator
Accessories
3G3IV-PCN126
3G3IV-PCN326
Digital operator extension cable
1 meters
3 meters
-----
3G3IV-PCN329-E PC configuration cable
-----
DATA
(15.5)
STOP
78 (3.07)
18.2
(0.72)
88 (3.46)
5
(0.2)
80 (3.15)
4-4.4 DIA. MTG HOLES
58 (2.28)
11
(0.43)
70 (2.76)
15.5 (0.61)
23.1
(0.91)
50 (1.97)
10.5
(0.41)
30.4
(1.20)
1.7
(0.07)
12.2
(0.48)
68 (2.68)
56 (2.20)
4-M4 SPOT FACING
DEEP 3.5 (0.14)
DSPL
STOP
RESET
DATA
ENTER
78 (3.07)
18.2
(0.72)
88 (3.46)
5
(0.2)
80 (3.15)
4-4.4 DIA. MTG HOLES
58 (2.28)
11
(0.43)
70 (2.76)
15.5 (0.61)
23.1
(0.91)
50 (1.97)
10.5
(0.41)
30.4
(1.20)
68 (2.68)
56 (2.20)
4-M4 SPOT FACING
DEEP 3.5 (0.14)
RUN
DIGITAL
OPERATOR
JVOP-140
MIN MAX
12.2 (0.48)
12.2 (0.48)
12.2 (0.48)
9.3 (0.37)
9.3 (0.37)
9.3 (0.37)
1.7 (0.07)
1.7 (0.07)
1.7 (0.07)
