ZFV
C-3ZFV
Amplifier Units
Item ZFV-CA40 ZFV-CA45
Output specifications NPN open collector, 30 VDC 50 mA max.,
residual voltage 1.2 V max.
PNP open collector, 50 mA max.,
residual voltage 1.2 V max.
Input
specifications
ON Short-circuited with 0 V terminal or 1.5 V or less Supply voltage short-circuited or within supply
voltage -1.5 V max.
OFF Open (leakage current 0.1 mA max) Open (leakage current 0.1 mA max)
Serial I/O USB2.0 1 port, full-speed (12 Mbps) MINI-B
RS-232C 1 port, 115,200 bps max.
Inspection items PATTERN, AREA, HUE (Color), WIDTH, POSITION, COUNT, BRIGHT, CHARA
Teaching area Rectangular, one area
Teaching area size PATTERN, BRIGHT: Any rectangular area (256 × 256 max.)
AREA, HUE (Color), WIDTH, POSITION, COUNT, CHARA: Any rectangular area (full screen max.)
Sensing area Full screen
Resolution 468 x 432 (H x V) max.
Bank switching Supported for 8 banks.
Image input interval 13 ms (Standard), 8 ms (1/2 for partial scan), 5 ms (1/4 for partial scan)
Other functions Control output switching: ON for OK / ON for NG, ON delay / OFF delay, One-shot output, "ECO" mode
Output signals (1) Control output (OUTPUT)
(2) Enable output (ENABLE)
(3) Error output (ERROR)
Input signals (1) Sync measurement input (TRIG)/Continuous measurement input (TRIG); switched by menu
(2) Bank selection inputs (BANK1-3)
(3) Workpiece still teaching (TEACH)/ Workpiece moving teaching (TEACH); switched by menu
Sensor head interface Digital interface
Image display 1.8 inch TFT ccolor LCD (Display dots: 557 x 234 pix)
Indicators Judgment result indicator (OUTPUT, Color: orange)
Inspection mode indicator (RUN, Color: green)
Error indicator (ERR, Color: red)
Ready status indicator (READY, Color: blue)
Operation interface Cursor keys (up, down, left, right)
Setting key (SET)
Escape key (ESC)
Operating mode switching (slide switch)
Menu switching (slide switch)
Teaching/Display switching key (TEACH/VIEW)
Function keys (A to D 4 input)
Power supply voltage
20.4 to 26.4 VDC (including ripple)
Current consumption
800 mA max. (with Sensor Head connected)
Dielectric strength
1,000 VAC, 50/60 Hz for 1 min between leads and Amplifier Unit case
Noise resistance
1 kV, Pulse rise: 5 ns, Pulse width: 50 ns, Burst duration: 15 ms, Cycle: 300 ms
Vibration resistance (destructive) 10 to 150 Hz, 0.1 mm single amplitude, 10 times each in X, Y, and Z directions for 8 min
Shock resistance (destructive)
150 m/s
2
, three times each in six directions (up/down, left/right, forward/backward)
Ambient temperature range
Operating: 0 to 50 °C
Storage: –25 to 65 °C (with no icing or condensation)
Ambient humidity range
Operating and storage: 35% to 85% (with no condensation)
Ambient atmosphere
Must be free of corrosive gas.
Degree of protection
IEC 60529, IP20
Material
Polycarbonate (PC)
Weight
Approx. 300 g (including cord; packaged condition: 450 g)
Accessories
Ferrite core (1), Instruction sheet, Label (1)
