APPENDIX E
E.WLCSP Bill of Materials
This appendix lists the parts that were used to make the WLCSP Evaluation and Development Board.
Table 12. Bill of Materials for RSL10 WLCSP Evaluation and Development Board Version 1.2
Designator Description Footprint Doc
Manufacturer Part
Number
Supplier part number
C3, C20 Capacitor, X5R, ±10% 0603 GRM188R61A475KE15D 490-10477-1-ND
C5, C45 Capacitor, NP0, ±2% 0402 GRM1555C1H101JA01J 490-7754-1-ND
C6, C8 Capacitor, NP0, ±2% 0402 GJM1555C1H1R5BB01D 490-8087-1-ND
C7 Capacitor, NP0, ±2% 0402 GRM1555C1E120GA01D 490-8169-1-ND
C11, C18, C21, C46,
C47, C50, C51
Capacitor, NP0, ±2% 0402 GRM155R61A105KE15D 490-3890-1-ND
C17 Capacitor, NP0, ±2% 0402 GRM155R61A225KE95D 490-10451-1-ND
C4, C22, C23, C24,
C25, C27, C29, C31,
C33, C34, C35, C36,
C37, C40, C41, C42,
C43
Capacitor, NP0, ±2% 0402 GRM155R61E104KA87D 490-5920-1-ND
C26 Capacitor, NP0, ±2% 0402 GRM1555C1E100JA01D 490-6168-1-ND
C28, C38, C39 Capacitor, X5R, ±10% 0603 GRM188R61A106KE69D 490-10474-1-ND
C30, C32 Capacitor, NP0, ±2% 0402 GRM1555C1E180JA01D 490-6172-1-ND
C49, C52 Capacitor, NP0, ±2% 0402 GRM155R71H103KA88D 490-4516-1-ND
D1 TVS DIODE 5.5VWM
SOT143B
SOT-143B PRTR5V0U2X,215 1727-3884-1-ND
J1 Coaxial Connector with
Switch
COAXIAL-SWF MM8130-2600RA2 490-4981-1-ND
J2 MicroUSB-B-SMT FCI_10118193-0001LF 10118193-0001LF 609-4616-1-ND
L1 Inductor, 320mA, ±5% 0402 HK100515NJ-T 587-1521-1-ND
L2 Inductor, 320mA, ±5% 0402 LQG15HS1N8S02D 490-2613-1-ND
L3 Inductor, 320mA, ±5% 0402 LQG15HS3N0S02D 490-6570-1-ND
L4 Inductor, 80mA, ±10% 0603 CBMF1608T2R2M 587-1718-1-ND
LD1 Ultra bright AlInGaP
Bi-Color LED
LED_DUAL_0606 LTST-C195KGJRKT 160-1452-1-ND
LED 1 LED SMARTLED
GREEN 570NM 0603
0603 LNJ337W83RA LNJ337W83RACT-ND
P1 Headers 16P STR SMT
DR GOLD 5.3MM
MATING PIN
HDR_2x8 961216-6300-AR-PR 517-9612166300ARPR
P2, P5 CONN HEADER 2POS
.100” SNGL SMD
HDR_2x1 TSM-102-01-L-SV SAM8979-ND
P3 SAMTEC - CONN
HEADER 10POS DUAL
.05” SMD KEYING
SHROUD
FTSH-105 FTSH-105-01-F-DV-K FTSH-105-01-F-DV-K-
P-TR-ND
