APPENDIX F
F.QFN Bill of Materials
This appendix lists the parts that were used to make the QFN Evaluation and Development Board.
Table 13. Bill of Materials for RSL10 QFN Evaluation and Development Board Version 1.3
Designator Description Footprint Doc
Manufacturer Part
Number
Supplier part number
AD1 Arduino Stackable
Header 6-pin
n/a SSQ-106-03-G-S SAM1198-06-ND
C2, C3, C4, C5, C6 Capacitor, NP0,
±2%
0402 GRM1555C1E120GA01D 490-8169-1-ND
C7 CAP CER 2.2UF
10V X5R 0402
0402 GRM155R61A225KE95D 490-10451-1-ND
C9, C16,C40 CAP CER 4.7UF
10V X5R 0603, CAP
CER 4.7UF 25V
X5R 0603
0603 GRM188R61A475KE15D 490-10477-1-ND
C11 Capacitor, NP0,
±2%
0402 GRM1555C1H101JA01J 490-7754-1-ND
C12, C13 CAP CER 1.5PF
50V NP0 0402
0402 GCM1555C1H1R5CA16D 490-13289-1-ND
C14 Capacitor, NP0,
±2%
0402 GRM1555C1E120GA01D 490-8169-1-ND
C10,C18, C19, C20,
C21, C23, C25,
C27, C29, C30,
C31, C32, C33,
C36, C37, C38,
C39,C48
Capacitor, NP0,
±2%
0402 GRM155R61E104KA87D 490-5920-1-ND
C22 Capacitor, NP0,
±2%
0402 GRM1555C1E100JA01D 490-6168-1-ND
C24, C34, C35 Capacitor, X5R,
±10%
0603 GRM188R61A106KE69D 490-10474-1-ND
C26, C28 Capacitor, NP0,
±2%
0402 GRM1555C1E180JA01D 490-6172-1-ND
C1, C8, C17, C41,
C42, C45, C46
Capacitor, NP0,
±10%
0402 GRM155R61A105KE15D 490-3890-1-ND
C44, C47 Capacitor, NP0,
±2%
0402 GRM155R71H103KA88D 490-4516-1-ND
D1 Ultra low
capacitance double
rail-to-rail ESD
protection diode
SOT-143B PRTR5V0U2X,215 568-4140-1-ND
IOH1 Arduino Stackable
Header 10-pin
SSQ-110-03-G-S SAM1198-10-ND
IOL1, POWER1 Arduino Stackable
Header - 8 Pin
SSQ-108-03-G-S SAM1198-08-ND
J1 Coaxial Connector
with Switch
COAXIAL-SWF MM8130-2600RA2 490-4981-1-ND
J2 MicroUSB-B-SMT FCI_10118193-0001LF 10118193-0001LF 609-4616-1-ND
