Section
1
Introduction
I
ABOUT THIS MANUAL
This manual provides service information for the Onan
KV
generator set.
It
is intended for the experienced
serviceperson. This manual covers troubleshooting,
disassembly, repair, reassembly, and adjustments for
the engine, generator, and control. The serviceperson
should be thoroughly familiar with the principles of gas-
oline engine operation and have a basic knowledge
of
electrical fundamentals. Other Onan publications such
as Electrical/Mechanical Fundamentals (932-0408),
Onan Generator Training Manual (932-0404), and
KV
Operator’s Manual
(981
-01
29) and Installation Manual
(981
-0626) are recommended as additional sources of
information.
I
MODEL IDENTIFICATION
When contacting an Onan dealer or distributor, always
supply the complete Model number and Serial number
as shown on the Onan nameplate. This information is
necessary to identify the set when ordering replacement
parts. See Figure
1.
Always use genuine Onan replacement parts obtained
from an authorized Onan dealer or distributor. Universal
replacement type parts (usually intended for automotive
use) often look similar but do not Derform to Onan speci-
fications. Only genuine Onan ieptacement
designed and tested for the application.
parts are
Read all service procedures completely before begin-
ning any repair work and observe all cautions and warn-
ings. It is extremely important that the generator set
installation maintain compliance with the applicable
codes and standards for
RV
installations (see Installa-
tion Manual). The most critical areas of concern include
the exhaust system, fuel system, electrical wiring, com-
partment construction, and ventilation system. Improper
service can create an unsafe installation that can result
in damage
to
the vehicle and equipment and can cause
severe personal injury or death to the user.
l
AWARNING
I
H
Serial
NO.
I
PF
Amps
Hz
FIGURE
1.
ONAN NAMEPLATE
INCORRECTSERVICE
OR
REPLACEMENT OF PARTS CAN RESULTIN SEVERE
PERSONAL INJURY, DEATH, AND/OR EQUIPMENT DAMAGE. SERVICE PER-
SONNEL MUSTBE QUALIFIED TO PERFORM ELECTRICAL AND/OR MECHAN-
ICAL SERVICE.
1-1
