WIFI configuration
There are two WIFI modes for Y series controller: AP mode and STA mode. (If there no
wireless card, please prepare one USB wireless card.)
1. AP mode (controller is hotspot, as to connect controller’s WIFI by PC)
Step 1
Open network connection on PC, the hotspot name of controller is the barcode of
controller, as below:
Step 2
Input passwords, initial password of controller is last 8 digits of barcode, then click
“next”, your PC will connect with controller wifi, as below:
Step 3
Open LedshowYQ 2018, you can operate normally.
Step 4
Users can modify WIFI name and passwords. “setup”--“WIFI configuration”--
passwords “168”-- select “AP WiFi”, input new WIFI name and passwords -- click “set”, it
will be modified successfully. (name cannot be set as Chinese, passwords support numbers,
characters, 8-12 digits.)
If users do not want to use controller WIFI, you can close it.
