13
User Manual
Dolphin Fluid Immersion Simulation
®
System
Dolphin Fluid Immersion Simulation
®
is a registered trademark of Joerns
Maintenance
Warning: Only facility-authorized personnel
trained by OnCare should perform preventative
maintenance. Preventative maintenance performed
by unauthorized personnel could result in personal
injury or equipment damage.
Any maintenance done without OnCare’s
authorization will invalidate any warranties on this
product.
Storage and Care
When the product is not in use, store the power cord
properly. Failure to do so could result in personal
injury.
Note: Clean the Dolphin FIS System as described in
the previous section prior to storage.
Control Unit
The power cord may be stored in the space provided
under the unit for convenience. Wrap the unit in a
plastic bag for dust resistance then store the unit in
an area appropriate for an electronic medical device.
Turn the Storage switch to Storage Mode when not in
use. The Storage switch is located at the underside
of the unit.
Therapy Mattress and Specialty Surfaces
Gently roll up the therapy mattress or specialty
surface, expelling any residual air, for temporary
storage. The therapy mattress or specialty surface
should be wrapped in plastic and/or a clean bag for
storage.
System Specications
Weight
Control Unit: .................................. 10 lbs (4.5 Kg)
Therapy Mattress: ...........................22 lbs (10 Kg)
Wheelchair Cushion: .........................5 lbs (2.3 Kg)
Safe Working Load
Therapy Mattress:
Maximum weight capacity
1
: ...... 1000 lbs (454.5 Kg)
Wheelchair Cushion:
Maximum weight capacity
2
.......... 250 lbs (113.6 Kg)
Dimensions
Control Unit:
11.5" (29.2 cm) W x 12.5" (31.8 cm) H x 6" (15.2 cm) D
Standard Therapy Mattress:
35" (89 cm) W x 82" (208 cm) L x 10" (25 cm) D
42" (107 cm) W x 82" (208 cm) L x 10" (25 cm) D
48" (122 cm) W x 82" (208 cm) L x 10" (25 cm) D
Low Prole Therapy Mattress:
35" (89 cm) W x 82" (208 cm) L x 8" (20 cm) D
42" (107 cm) W x 82" (208 cm) L x 8" (20 cm) D
48" (122 cm) W x 82" (208 cm) L x 8" (20 cm) D
Step-Deck (Dolphin V-Matt):
35" (89 cm) W x 88" (224 cm) L x 10" (25 cm) D
Wheelchair Cushion:
17" (43 cm) W x 17" (43 cm) L x 4" (10 cm) D
Electrical Specications
USA:
115V AC, 60 Hz
Environmental Conditions
Operating Conditions:
Ambient Temperature: +10°C to +40°C
Relative Humidity: 30% to 75% Non-Condensing
Storage and Shipping Conditions:
Ambient Temperature: 10ºC to +40ºC
Relative Humidity: 10% to 100%
Control Unit Agency Approval
Conforms to UL 60601-1 and IEC 60601-1-2,
Certied to CAN/CSA C22.2 No. 601.1
Call for Assistance
If you have any questions or require service
on a OnCare product, please call OnCare at
800.847.7368.
1
Mattress weight capacity only; total weight must not
exceed bed frame manufacturers’ specied load capacity,
and when paired with an appropriate surface.
2
Specialty surface weight capacity only; total weight must
not exceed wheelchair manufacturers’ specied load
capacity, and when paired with an appropriate surface.
