Onda V-10 PLUS - Main Specifications

3
Caution, Danger!
Caution, High Voltage!
Caution, Hot!
Ground
Fuse
Recycle, this instrument will be called back by the appointed
Electrical Treatment Department or by the original Manufacturer
when wasted.
Main Specifications
 Optical System Single beam
 Wavelength Range 325—1000nm
 Wavelength Accuracy ±2nm
 Wavelength Repeatability 0.8nm
 Photometric Range -0.3—3A, 0—200%T
 Photometric Accuracy ±0.5%T
 Photometric Repeatability 0.3%T
 Spectral Bandwidth 4nm
 Stray Light 0.3%T@360nm
 Stability ±0.002A/h@500nm
 Work Mode Photometry, Quantitation
 Interface USB, Parallel(printer)
 Power Requirement AC 110/220V, 50/60Hz
 Dimensions 490x360x210
 Weight 14kg
 Work Environment 15—35℃, 15—70% relative humidity
 Store Environment -10—50℃, 15—70% relative humidity
