TWIN USER’S MANUAL
11
04
uSe and conFiguration oF the equiPMent
3. Make sure the four pins are not visible and be aware of the positioning
while inserting it. Only one way is possible
according to its geometry.
4. Once the Battery is inserted in the board,
insert the four pins to lock the Battery.
If the pins do not enter easily, please,
press down on the battery so the watertight seal is sufficiently
compressed.
5. Close the vent completely, turning it clockwise to assure watertightness.
6. In order to ease the extraction of the battery, turn the vent one full round
counter-clock wise. Pull from the upper handle perpendicularelly to
extract the battery.
7. Always keep the vent closed in any other moment
and do not turn it more than three full turns.
Battery
Compartment
Board
Connectors
Antenna´s LED
