Onean TWIN - Use and Configuration: Controller Modes and Settings; Synchronization and Max Power Modes; Controller Sensitivity Settings

TWIN USER’S MANUAL
14
04
Use and ConfigUration of the eqUipment
2. On this position, press on the drop until
the first LED of the board display on the
controller begins to blink. At this moment,
the LED bar will progressively light up. Each
position represents a different function.
a) Synchronization. 1St Led bLinking
Always with the battery initially disconnected, and once the rst LED
begins to blink, you must press on the drop again to access the submenu.
In this submenu, the controller will start searching for a board for a
few seconds and the sync LED will begin to blink.
As the sync LED is blinking the
battery must be inserted to
complete the synchronization
(see 4.1.2.).
Once the board is synched, both LEDs will
blink at a higher pace indicating that the
process has been successfully completed.
b) MaxiMuM Power. 2 LedS bLinking
Once the rst two LEDs start ashing you must press on the drop
to access this submenu.
The power bar will progressively light up. Press on the drop to set
the desired value according to the following description.
c) controLLer SenSitivity. 3 LedS bLinking
Once the rst three LEDs are ashing you must press on the drop to
access the submenu.
The power bar will progressively light up. Press on the drop to set
the desired value according to the following description.
• 1 LED: Staggered 1.
• On this profile we have discretized the power levels of
the jet in 5 different ranges of pressure on the drop. It
allows us to control and hold the pressure on each range.
SYNC BATTERY
LED Blinking
2
SYNC BATTERY
LEDs Power [W] Display
1 LEDs 800 W
2 LEDs 1.200 W
3 LEDs 2.600 W
4 LEDs 3.700 W Factory Settings
5 LEDs 5.000 W
Power %
Low
0
20
40
60
80
100
Medium High
Staggered 1
