Onkyo C-705X User Manual

2
Thank you for purchasing ...
Before using
Main Features
Thank you for purchasing Onkyo C-705X CD player.
Please read this manual thoroughly before making connections and plugging in the unit.
Following the instructions in this manual will enable you to obtain optimum performance and listening
enjoyment from your new C-705X.
Please retain this manual for future reference.
• High-Quality Separate Component
• Dual-Channel Optical Digital Outputs
• Linear Single-bit D/A Converter
• TR-1 Play Mode (for playing only the first song)
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
AVIS
“CLASS 1 LASER
PRODUCT”
This unit contains a semiconductor laser system and is
classified as a “CLASS 1 LASER PRODUCT”. So, to use
this model properly, read this Instruction Manual
carefully. In case of any trouble, please contact the store
where you purchased the unit. To prevent being exposed
to the laser beam, do not try to open the enclosure.
DANGER:
INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCK FAILED OR DEFEATED. AVOID DIRECT
EXPOSURE TO BEAM.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
This label on the rear panel states that:
This unit is a CLASS 1 LASER PRODUCT
and employs a laser inside the cabinet.
To prevent the laser from being
exposed, do not remove the cover.
Refer servicing to qualified personnel.
1.
2.

Onkyo C-705X Specifications

Audio Specifications

sampling frequency	352.8 kHz
frequency response	5 Hz – 20 kHz
total harmonic distortion	0.005% (at 1 kHz)
dynamic range	96 dB
signal to noise ratio	90 dB
channel separation	85 dB (at 1 kHz)
output level	2 volts r.m.s.

Power

power consumption (230 V, 50 Hz model)	8 watts
power consumption (120 V, 60 Hz model)	9 watts
power supply rating (230 V, 50 Hz)	AC 230 V, 50 Hz
power supply rating (120 V, 60 Hz)	AC 120 V, 60 Hz

Weight and Dimensions

dimensions	205 x 91 x 275 mm
dimensions (inch)	8-1/16" x 3-9/16" x 10-3/16"
weight	2.2 kg, 4.9 lbs.
