Onkyo C-705X User Manual

24
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 0720-31-8111 Fax: 0720-33-5222 http://www.onkyo-intl.com
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.onkyo.net
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: 852 2429 3118 Fax: 852 2428 9039
E
http://www.onkyo.co.jp/
HOMEPAGE
SN 29342739
Printed in Japan
I9905-1
Specifications
Signal readout system : Optical non-contact
Reading rotation : About 500 – 200 r.p.m.
(constant linear velocity)
Linear velocity : 1.2 –1.4 m/s
Error correction system :
Cross Interleave Reed Solomon code
D/A converter : 1 bit D/A converter
Sampling frequency : 352.8 kHz
(Eight-times oversampling)
Number of channels : 2 (stereo)
Frequency response : 5 Hz – 20 kHz
Total harmonic distortion : 0.005% (at 1 kHz)
Dynamic range : 96 dB
Signal to noise ratio : 90 dB
Channel separation : 85 dB (at 1 kHz)
Wow and Flutter:
Below threshold of measurability
Output level : 2 volts r.m.s.
Power consumption :
230 V, 50 Hz model : 8 watts
120 V, 60 Hz model : 9 watts
Power supply rating :
AC 230 V, 50 Hz
AC 120 V, 60 Hz
Dimensions (W x H x D) :
205 x 91 x 275 mm
8-1/16" x 3-9/16" x 10-3/16"
Weight : 2.2 kg, 4.9 lbs.
Specifications and external appearance are subject to
change without notice because of product improvements.

Onkyo C-705X Specifications

Audio Specifications

sampling frequency	352.8 kHz
frequency response	5 Hz – 20 kHz
total harmonic distortion	0.005% (at 1 kHz)
dynamic range	96 dB
signal to noise ratio	90 dB
channel separation	85 dB (at 1 kHz)
output level	2 volts r.m.s.

Power

power consumption (230 V, 50 Hz model)	8 watts
power consumption (120 V, 60 Hz model)	9 watts
power supply rating (230 V, 50 Hz)	AC 230 V, 50 Hz
power supply rating (120 V, 60 Hz)	AC 120 V, 60 Hz

Weight and Dimensions

dimensions	205 x 91 x 275 mm
dimensions (inch)	8-1/16" x 3-9/16" x 10-3/16"
weight	2.2 kg, 4.9 lbs.
