Onkyo C-N7050 User Manual

18
Using network services
vTuner Internet Radio
vTuner Internet Radio is a portal site for Internet
radio stations around the world. You can search for
radio stations by musical genre, country and other
classifications.
vTuner Internet Radio has been added to this unit in
advance.
⿠
An Internet connection is necessary to listen to vTuner
Internet Radio.
1. Press the NET button to open the network service
menu.
Network service menu
Press the NET button and press the direction
(
/ / / ) buttons to select the menu as follows.
vTuner Internet Radio -> My Favorites -> DLNA ->
Home Media
2. Use the direction ( / / / ) buttons to select “vTuner
Internet Radio” and press the ENTER button.
An error message will appear if the service is not on
the air.
3. Use the direction ( / ) buttons to select a station and
press the ENTER button.
Playback will start.
⿠
To see similar stations, press and hold the remote
control MENU button, use the direction ( / )
buttons to select “Stations like this” and press the
ENTER button.
Store favorite vTuner Internet Radio programs
You can store specific vTuner Internet Radio programs as
favorites to make accessing them easier. There are two
ways to do this.
1
Add it to My Favorites
Press the NET button to open the network service menu
and use the “My Favorites” item to add a favorite program
to it.
1. After selecting the radio station to add, press and hold
the remote control MENU button.
⿠
You can add a radio station even while it is playing
back.
2. Use the direction ( / ) buttons to select “My
Favorites” and press the ENTER button.
3. To add the radio station without changing its name,
use the direction ( / / / ) buttons to select “OK” and
press the ENTER button. To add the radio station after
changing its name, after using the direction ( / / / )
buttons to input the characters, select “OK” and press
the ENTER button.
Inputting characters: See "Inputting characters" in
"Other operations".
Assigning to the PRESET buttons
Long pressing one of the PRESET 1 to 3 buttons
while you are playing back an Internet radio station,
allows you to set it to the PRESET button.
2
Add a station to My Favorite Groups in
vTuner Internet Radio
Select vTuner Internet Radio and press the ENTER
button to see the “My Favorite Groups” folder on the
same screen that shows genres and locations. You can
add Internet radio stations that you like to this folder.
Before starting the procedure
This procedure requires a computer.

Onkyo C-N7050 Specifications

General

Frequency range	10 - 70000 Hz
Audio formats supported	AAC, FLAC, MP3, OGG, WAV, WMA
Signal-to-Noise Ratio (SNR)	115 dB
Total Harmonic Distortion (THD)	0.0003 %
CD-R playback	Yes
CD changer	No
Device type	HiFi CD player
Product color	Black
Housing material	Metal
Disc loading type	Tray
Disc types supported	CD, CD-R, CD-RW
Number of optical discs	1 discs
Cables included	RCA
Power source type	AC, Battery
AC adapter frequency	50 Hz
AC adapter input voltage	220 - 240 V
Power consumption (typical)	30 W
Number of batteries supported	2
Display type	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	1
Battery type	AAA
Dimensions (WxDxH)	435 x 302 x 102 mm
Package weight	6400 g

Weight and Dimensions

Weight	4600 g
