En-7
Getting to Know the CBX-500/CBX-600UKD
The page numbers in parentheses show where you can find the main explanation for each item.
a ON/STANDBY button (18, 49, 53)
b CD slot/door (20)
c INPUT button (18)
d iPod Play/Pause [/] button (29)
e Previous and Next [/]/[/]
buttons (21, 29, 40)
f Stop [] button (20)
g CD Play/Pause [/] button (20)
h CBX-500 European model:
USB Play/Pause [/] button (20)
CBX-500 North American and CBX-600UKD
models:
DISPLAY button (23, 25, 30, 35, 44)
i SNOOZE (51)
j VOLUME []/[] buttons (18)
k iPod Dock (29)
l STANDBY indicator (17, 18)
m Display
n Remote control sensor (11)
o USB port (CBX-500 European model only)
(20)
Top and Front Panels
To Next Page
