1/2 PAGE
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. (D) : Wood color model
<CDC> : 120V
North American model
<CMP> : 220-240V
European model
<CJJ> : 100V
Japan model
: NSP
CP-1050
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[CHASSIS SCREW]
D201,D202,
LED(AMBER,LTL-1CHKFK,
∮
3.1)
2 410-1300-243
E01 HINGE SLIDE 2 100-DJ3000-1350
E02 GROUND TERMINAL 1 200-GND-642
E03 REAR BOARD 1 300-CP1050A-2185 CDC
E03 REAR BOARD 1 300-CP1050B-2185 CMP
↓
300-1050B1-2185
E03 REAR BOARD 1 300-CP1050C-2185 CJJ
E04 FEET 4 701-CP1050-4606
E05 LARGE BUTTON 2 701-CP1050-5472
E07 AC SOCKET(SO-222) 1 404-DJ2-021 CDC
E07 AC SOCKET(SO-222-S-0-R6(d)) 1 404-HDJ2200E-969 CMP,CJJ
E08 TONE ARM ASS'Y 1 704-CP1050-B118 Service Part
FU01, FUSE(500mA/250V,UL/CSA,51S0500H,PB FREE) 1 422-270X-033 CDC,CJJ
FU01, FUSE(TSD,500mA/250V 50F VDE L=20mm) 1 422-KT350A-003 CMP
JK601 2P RCA JACK(RJ-1078-10-0500A) 1 420-RCC955A-089
SW1, POWER SW(SDDLB1007U-HF3) 1 403-1300-180
SW201 PUSH SW(SPUN12A010-HF) 1 403-1300-181
T901 TRANSFORMER(AC120V,60Hz) 1 411-1050-941 CDC
T901 TRANSFORMER(AC230V,50Hz) 1 411-1050-940 CMP
T901 TRANSFORMER(AC100V,50/60Hz) 1 411-1050-942 CJJ
TX1 TRANSFORMER(AC230V,50Hz) 1 411-1050-939 CMP
[TUNER UNIT]
U01 MAIN PCB ASS'Y 1 704-1050-B053 CDC,CJJ
U01 MAIN PCB ASS'Y 1 704-1050B-B061 CMP
U02 AC PCB ASS'Y(UL) 1 704-1050-B055 CDC,CJJ
U02 AC PCB ASS'Y(VDE) 1 704-1050B-B062 CMP
U03 D.D.MOTOR ASS'Y 1 704-CP1050-B066
↓
↓↓
↓ ↓
↓↓
↓
D.D.MOTOR Packing ASS'Y 705-CP1050-1636
[Others]
Stylus for customer service.
SV01 ONKYO DN-105ST (Red) 1 242987
or
(Substitute) Audio-Technica Corporation ATN-3600L (White) 1 --- Information
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART
To Next Page
