Onkyo CR-315

3/22 PAGE
EV
Q557 or TR 2SD1267-P (1) 2204053
!
EV
Q558 TR 2SC3851-O 1 2203383
!
EV
Q558 or TR 2SC3851-Y (1) 2203384
!
EV
Q558 or TR 2SD1267-Q (1) 2204052
!
EV
Q558 or TR 2SD1267-P (1) 2204053
!
EV
Q559 TR 2SA1488-O 1 2203393
!
EV
Q559 or TR 2SA1488-Y (1) 2203394
!
EV
Q559 or TR 2SB942-Q (1) 2204042
!
EV
Q559 or TR 2SB942-P (1) 2204043
!
EV
Q560 TR 2SA1488-O 1 2203393
!
EV
Q560 or TR 2SA1488-Y (1) 2203394
!
EV
Q560 or TR 2SB942-Q (1) 2204042
!
EV
Q560 or TR 2SB942-P (1) 2204043
!
EV
<Note>
EV
Must use the same HFE rank mutually about the following parts.
EV
Ref. No. : Q557 - Q559, Q558 - Q560
EV
T901 P TRANS NPT-1545P 1 2301874
!, <MPP>
EV
T901 P TRANS NPT-1545D 1 2301873
!, <MDC>
EV
T901 P TRANS NPT-1545P 1 2301874
!, <MGT>
EV
T901 P TRANS NPT-1545D 1 2301873
!, <MDT>
EV
T901 P TRANS NPT-1545P 1 2301874
!, <MGQ>
EV
T901 P TRANS NPT-1545P 1 2301874
!, <DAB MPB>
EV
U01 PRE-AMP. MICROPROCESSOR PC board ass'y NAAR-8931-1A 1 1B147531-1A <MPP>
EV
U01 PRE-AMP. MICROPROCESSOR PC board ass'y NAAR-8931-1B 1 1B147531-1B <MDC>
EV
U01 PRE-AMP. MICROPROCESSOR PC board ass'y NAAR-8931-1C 1 1B147531-1C <MGT>
EV
U01 PRE-AMP. MICROPROCESSOR PC board ass'y NAAR-8931-1E 1 1B147531-1E <MDT>
EV
U01 PRE-AMP. MICROPROCESSOR PC board ass'y NAAR-8931-1D 1 1B147531-1D <MGQ>
EV
U01 PRE-AMP. MICROPROCESSOR PC board ass'y NAAR-8931-1F 1 1B147531-1F <DAB MPB>
EV
U02 CD PC board ass'y NADG-8932-1A 1 1B147532-1A <MPP>
EV
U02 CD PC board ass'y NADG-8932-1B 1 1B147532-1B <MDC>
EV
U02 CD PC board ass'y NADG-8932-1C 1 1B147532-1C <MGT>
EV
U02 CD PC board ass'y NADG-8932-1E 1 1B147532-1E <MDT>
EV
U02 CD PC board ass'y NADG-8932-1D 1 1B147532-1D <MGQ.
EV
U02 CD PC board ass'y NADG-8932-1F 1 1B147532-1F <DAB MPB>
EV
U04 DAB TERMINAL PC board ass'y NAETC-8934-1F 1 1B147534-1F <DAB MPB>
EV
U05 DISPLAY PC board ass'y NADIS-8935-1A 1 1B147535-1A <MPP>
EV
U05 DISPLAY PC board ass'y NADIS-8935-1B 1 1B147535-1B <MDC>
EV
U05 DISPLAY PC board ass'y NADIS-8935-1C 1 1B147535-1C <MGT>
EV
U05 DISPLAY PC board ass'y NADIS-8935-1E 1 1B147535-1E <MDT>
EV
U05 DISPLAY PC board ass'y NADIS-8935-1D 1 1B147535-1D <MGQ>
EV
U05 DISPLAY PC board ass'y NADIS-8935-1F 1 1B147535-1F <DAB MPB>
EV
U06 POWER AMPLIFIER PC board ass'y NAAF-8936-1A 1 1B147536-1A <MPP>
EV
U06 POWER AMPLIFIER PC board ass'y NAAF-8936-1B 1 1B147536-1B <MDC>
EV
U06 POWER AMPLIFIER PC board ass'y NAAF-8936-1C 1 1B147536-1C <MGT>
EV
U06 POWER AMPLIFIER PC board ass'y NAAF-8936-1E 1 1B147536-1E <MDT>
EV
U06 POWER AMPLIFIER PC board ass'y NAAF-8936-1D 1 1B147536-1D <MGQ>
EV
U06 POWER AMPLIFIER PC board ass'y NAAF-8936-1F 1 1B147536-1F <DAB MPB>
EV
U07 POWER SUPPLY PC board ass'y NAPS-9837-1A 1 1B147537-1A <MPP>
EV
U07 POWER SUPPLY PC board ass'y NAPS-9837-1B 1 1B147537-1B <MDC>
EV
U07 POWER SUPPLY PC board ass'y NAPS-9837-1C 1 1B147537-1C <MGT>
EV
U07 POWER SUPPLY PC board ass'y NAPS-9837-1E 1 1B147537-1E <MDT>
EV
U07 POWER SUPPLY PC board ass'y NAPS-9837-1D 1 1B147537-1D <MGQ>
EV
U07 POWER SUPPLY PC board ass'y NAPS-9837-1F 1 1B147537-1F <DAB MPB>
EV
U08 SPEAKER TERMINAL PC board ass'y NAETC-8938-1B 1 --- NSP, <MDC>
EV
U09 SPEAKER TERMINAL PC board ass'y NAETC-8939-1A 1 --- NSP, <MPP>
EV
U09 SPEAKER TERMINAL PC board ass'y NAETC-8939-1C 1 --- NSP, <MGT>
