4/22 PAGE
EV
U09 SPEAKER TERMINAL PC board ass'y NAETC-8939-1E 1 --- NSP, <MDT>
EV
U09 SPEAKER TERMINAL PC board ass'y NAETC-8939-1D 1 --- NSP, <MGQ>
EV
U09 SPEAKER TERMINAL PC board ass'y NAETC-8939-1F 1 --- NSP, <DAB MPB>
EV
U10 TUNER UNIT FAE485-E11EU 1 240154 <MPP>
EV
U10 TUNER UNIT ENG06507QFUS 1 240156 <MDC>
EV
U10 TUNER UNIT FAE485-E12EX 1 240155 <MGT>
EV
U10 TUNER UNIT FAE485-E12EX 1 240155 <MDT>
EV
U10 TUNER UNIT ENG07506QFEX 1 240159 <MGQ>
EV
U10 or TUNER UNIT FAE485-E12EX (1) 240155 <MGQ>
EV
U10 TUNER UNIT FAE485-E11EU 1 240154 <DAB MPB>
EV
U11 DAB MODULE VENICE3.0-C-F 1 24150071 <DAB MPB>
CR-315/315DAB
EXPLODED VIEW PARTS LIST OF MECHANIS
CD MECHANISM : DLM1A01-14CA / KSM-213CLCM
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. REMARKS
CD1
Z005 CD Tray loading unit DLM1A01-14CA 1 24800056
CD1
Z006 CD Drive unit KSM-213CLCM 1 24800017
CD1
Z007 INSULATOR (CDC-A) 4 24818058
CD1
Z008 SPRING TP-D (silver) 2 24820071
CD1
Z009 SPRING TP-E (gold) 2 24820072
CD1
Z010 SCREW 2.6 x 8 x w10 4 801632
CD TRAY LOADING UNIT : DLM1A01-14CA
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. REMARKS
CD2
1 CHASSIS --- 1 65-210-1054
CD2
2 TRAY --- 1 65-218-1055
CD2
3 SUB CHASSIS --- 1 65-211-2040
CD2
4 CAM SLIDER --- 1 65-239-2004
CD2
5 GEAR TRAY --- 1 65-222-3005
CD2
6 CLAMPER ASS'Y --- 1 65-093-4057H
CD2
7 PWB ASS'Y --- 1 65-093-4058H
CD2
8 GEAR A --- 1 65-222-4037
CD2
9 PULLEY GEAR --- 1 65-222-4004
CD2
10 MOTOR ASS'Y --- 1 65-093-4068H
CD2
11 LOADING BELT --- 1 02-083-4274
CD2
12 SCREW --- 2 GSP14A25027
CD DRIVE UNIT : KSM-213CLCM
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. REMARKS
CD3
51 Motor chassis ass'y --- 1 X-2656-877-1
CD3
52 Motor gear ass'y --- 1 X2625-769-1
CD3
53 Sled shaft --- 1 2626-908-01
CD3
54 Gear (A) (S) --- 1 24810023
CD3
55 P2 x 3, Screw --- 2 7621-255-15
CD3
56 Leaf switch --- 1 24840008
CD3
57 Motor PC board --- 1 1639-678-12
CD3
58 Connector 6pin --- 1 1-564-722-11
CD3
61 KSS-213C, Pickup --- 1 8848-483-05
CR-315/315DAB
PC BOARD PARTS LIST
U01 PRE-AMP. & MICROPROCESSOR PC BOARD (NAAR-8931-1A / 1B / 1C / 1D / 1E / 1F)
U02 CD PC BOARD (NADG-8932-1A / 1B / 1C / 1D / 1E / 1F)
U04 DAB TERMINAL PC BOARD (NAETC-8934-1B)
