5/22 PAGE
<Note> U04 : DAB MPB Only
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PCB1
Q101 IC (SERVO MICROPROCESSOR) MPD784225GC-305-8BT-A 1 22242295R3
PCB1
Q102 IC TC74VHC541FT 1 22274541ER2TO
PCB1
Q201 IC BD7931F 1 22242216R2
PCB1
Q202 IC BA5947FP 1 22242215R2
PCB1
Q204 IC PQ033ENA1ZPH 1 22242334R2
PCB1
Q206 IC CXD3014AR 1 22242264R3
PCB1
Q207 IC MPD120N18T1B-E1-AZ 1 22278018NR2NE
PCB1
Q401 IC R2S15211FP 1 22242297R3
PCB1
Q707 IC S-24CS16A0I-J8V1G 1 22242326R2
PCB1
Q708 IC S-812C50AUA-C3E 1 22242240R2
PCB1
Q709 IC (MAIN MICROPROCESSOR) M30622MWP-B07FP 1 22242377R3
PCB1
Q710 IC S-80140CNMC-JKZ-T2 1 22242238R2
PCB1
Q902 IC S-80140CNMC-JKZ-T2 1 22242238R2
PCB1
Q904 IC MPC2906HF 1 22278006DNE
PCB1
Q905 IC UPC2905AHF-AZ 1 22278005DNE <DAB MPB>
PCB1
Q905 or IC MPC2905BHF (1) 22278005DBNE <DAB MPB>
PCB1
Q906 IC MPC2933AHF 1 22278033DNE <DAB MPB>
PCB1
Q906 or IC MPC2933BHF-AZ (1) 22278033DBNE <DAB MPB>
PCB1
Q906A HEAT-SINK HEAT-SINK(RAD-68) 1 27160211 <DAB MPB>
PCB1
Q906B SCREW 3P+10FN(3BC) 1 82143010GR <DAB MPB>
PCB1
Q907 IC MPC2905AT 1 22278005DR2NE
PCB1
Q907 or IC TA4805AF(TE16L_NQ) (1) 22278005DR2TO
PCB1
Q921 IC MPC2905AT 1 22278005DR2NE
PCB1
Q921 or IC TA4805AF(TE16L_NQ) (1) 22278005DR2TO
PCB1
Q925 IC 78M08HF(NJM78M08FA) 1 222780085JRC
PCB1
Q926 IC 79M08HF(NJM79M08FA) 1 222790085JRC
PCB1
Q951 IC 78M09HF(NJM78M09FA) 1 222780095JRC
PCB1
Q2209 IC NJM4580M-D 1 22241448R2
PCB1
Q208 TR 2SA1162-GR 1 2214375R2
PCB1
Q432 TR 2SC2712-GR 1 2213145R2
PCB1
Q433 TR 2SA1162-GR 1 2214375R2
PCB1
Q702 TR RN2403 1 2214540R2
PCB1
Q703 TR RN2402 1 2214530R2
PCB1
Q705 TR RN2403 1 2214540R2
PCB1
Q706 TR RN2403 1 2214540R2
PCB1
Q941 TR 2SA1015-GR 1 2211455T
PCB1
Q2210 TR RN1441 1 2215410R2
PCB1
Q2211 TR RN1441 1 2215410R2
PCB1
Q7101 TR RN1401(TE85L_F) 1 2214460R2 <DAB MPB>
PCB1
Q7102 TR RN2402 1 2214530R2 <DAB MPB>
PCB1
D101 C-DIODE 1SS355 1 223269R2
PCB1
D101 or C-DIODE 1SS352 (1) 223234R2
PCB1
D102 C-DIODE 1SS355 1 223269R2
PCB1
D102 or C-DIODE 1SS352 (1) 223234R2
PCB1
D201 C-DIODE 1SS355 1 223269R2
PCB1
D201 or C-DIODE 1SS352 (1) 223234R2
PCB1
D425 C-DIODE 1SS355 1 223269R2
PCB1
D425 or C-DIODE 1SS352 (1) 223234R2
PCB1
D701 ZENER D UDZS5.1B 1 224550510R2
PCB1
D702 C-DIODE 1SS355 1 223269R2
PCB1
D702 or C-DIODE 1SS352 (1) 223234R2
PCB1
D905 C-DIODE S1NB60-4062 1 22380318R2
PCB1
D906 DIODE D5SBA20 1 22380130F <MGT>
